Varnish Microlamination (VML) Dating

We provide rock varnish-based age estimates for surficial geological

and geoarchaeological features in the western US deserts.


VML Dating: An Introduction

       Rock varnish is a dark coating on subaerially exposed rock surfaces. It is probably the world's slowest-accumulating sedimentary deposit, growing at only a few to tens of microns per a thousand years (Liu and Broecker, 2000). Its thickness ranges from <5 µm to 600 µm, with a typical thickness of about 100 µm. Although found in all terrestrial environments, rock varnish is mostly developed and well preserved in arid to semiarid deserts of the world (Figure 1). It is composed of about 30% manganese and iron oxides, up to 70% clay minerals, and over a dozen trace and rare earth elements (Potter and Rossman, 1977, 1979). The building blocks of rock varnish are largely blown in as airborne dust (Fleisher et al., 1999; Moore et al., 2001; Thiagarajan and Lee, 2004).

       Microlaminations in rock varnish were first reported by Perry and Adams (1978), who recognized their potential as a paleoenvironmental indicator in drylands. Microlaminations can be observed when the varnish is shaved thin enough (5-10 µm) to see through in ultra-thin section with a light microscope (Figure 2). Electron microprobe chemical mapping reveals that dark layers in varnish thin section are rich in Mn and Ba, but poor in Si and Al, while orange and yellow layers are poor in Mn and Ba, but rich in Si and Al (Figure 3). These two types of layers are intercalated to form a distinct microstratigraphy.

       A growing body of evidence indicates that varnish microstratigraphy carries a climate record (Dorn, 1984; Dorn, 1990; Cremaschi, 1996; Liu and Dorn, 1996; Liu et al., 2000; Broecker and Liu, 2001; Lee and Bland, 2003). In the drylands of western USA (Figure 4), Mn-poor yellow layers (usually containing 5-15% MnO) formed during dry periods of the Holocene and the last interglacial, while Mn-rich black layers (usually containing 25-45% MnO) deposited during wet periods of the last glacial time; Mn-intermediate orange layers (usually containing 15-25% MnO) formed during periods of climatic transition between extremely dry and extremely wet condition (Broecker and Liu, 2001) (Figure 5). Furthermore, the glacial-age black layers in varnish microstratigraphy appear to correlate in time with the cold episodes of the Younger Dryas and Heinrich Events (Broecker, 1994; Bond et al., 1993) in the North Atlantic region (Liu and Dorn, 1996; Liu et al., 2000; Liu, 2003) (Figure 6 and Figure 7).

       Varnish microlamination (VML) as a correlative dating technique (cf. terminology in Colman et al., 1987) is relatively new and different in principle and independent of both cation-ratio and AMS 14C methods (Dorn, 1983; Dorn et al., 1989). It was first used by Dorn (1988) to study the chronostratigraphy of alluvial-fan deposits in Death Valley of California. Subsequent studies by others (Liu, 1994; Liu and Dorn, 1996; Liu, 2003) have greatly improved the usefulness of the technique. The basic assumption in this dating approach is that the formation of varnish microstratigraphy is largely influenced by regional climatic variations. Since climatic signals recorded in varnish have been proven to be regionally contemporaneous (Liu and Dorn, 1996; Liu et al., 2000), varnish microstratigraphy has the potential use as a tephrachronology-like dating tool. A rigorous blind test of this method has been conducted on late Quaternary lava flows in the Mojave Desert, California (Liu, 2003; Phillips, 2003). The test results demonstrate that varnish microstratigraphy is a valid dating tool to provide surface exposure age for late Pleistocene (i.e., 12 - 85 ka) surficial geomorphic features in the Great Basin of western USA (Marston, 2003) (Figure 8). New radiometric age calibration and climatic correlation of varnish microstratigraphy with the SPECMAP record have extended the utility of the VML method to surficial geomorphic and geoarchaeological features of late Quateranry (i.e., 0 - 300 ka) (Liu and Broecker, 2007) (Figure 9).

       As a unique dating technique, the VML method has great chronometric applications in earth science and geoarchaeology. Without age calibration, it can be used as a regional correlation and mapping tool (Liu and Dorn, 1996). Once radiometrically calibrated, it can yield minimum-limiting surface exposure ages for various geomorphic features (e.g., alluvial-fan surfaces, desert pavements, hillslope deposits, lava flows, debris flows, fault scarps, meteor crater) and geoarchaeological features (e.g., stone tools, petroglyphs, geoglyphs) (Figure 10) in the western USA drylands where other dating techniques such as radiocarbon and cosmogenic radionuclide methods are either not applicable or difficult to use. Since microstratigraphy has been observed in varnish from other deserts of the world (e.g., Negev Desert of Israel, Patagonia Desert of Argentina, Coastal Desert of Peru, Gürbantongüt Desert of western China, the Indus River Valley of Pakistan, and Strzelecki Desert of South Australia) (Figure 11), the VML method may also have potential chronometric applications in those desert regions of the world.

       (For further understanding of the VML dating technique and its chronometric applications in earth science and geoarchaeology, please go to Selected Publications; for more information about rock varnish in general and rockart sites in the western USA dryalnds, please go to Links at VML Dating Lab's website.)



References Cited

  1. Adams, K.D., Wesnousky, S.G., 1998. Shoreline processes and the age of the Lake Lahontan highstand in the Jessup embayment, Nevada. Geological Society of America Bulletin 110, 1318–1332.
  2. Alley, R., Meese, D., Shuman, C., Gow, A., Taylor, K., Grootes, P., White, J., Ram, M., Waddington, E., Mayewski, P., Zielinski, G., 1993. Abrupt increase in Greenland snow accumulation at the end of the Younger Dryas event. Nature 362, 527-529.
  3. Baied, C.A., Somonte, C., 2012. Mid-Holocene geochronology, palaeoenvironments, and occupational dynamics at Quebrada De Amaicha, Tucuman, Argentina. Quaternary International. http://dx.doi.org/10.1016/j.quaint.2012.11.025
  4. Bender, M., Sowers, T., Dickson, M.L., Orchardo, J., Grootes, P., Mayewskiy, P.A., Meese, D.A., 1994. Climate correlations between Greenland and Antarctica during the past 100,000 years. Nature 372, 663-666.
  5. Bond, G., Broecker, W., Johnson, S., McManus, J., Labeyrie, L., Jouzel, J., Bonani, G., 1993. Correlations between climate records from North Atlantic sediments and Greenland ice. Nature 365, 143-147.
  6. Bond, G.C., Showers, W., Cheseby, M., Lotti, R., Almasi, P., deMenocal, P., Priore, P., Cullen, H., Hajdas, I., Bonani, G., 1997. A pervasive millennial-scale cycle in North Atlantic Holocene and glacial climates. Nature 278, 1257-1266.
  7. Bond, G.C., Showers, W., Elliot, M., Evans, M., Lotti, R., Hajdas, I., Bonani, G., Johnson, S., 1999. The North Atlantic's 1-2 kyr climate rhythm, relation to Heinrich events, Dansgaard/Oeschger cycles and the little ice age. In: Clark, P.U., Webb, R.S., Keigwin, L.D. (Eds.), Mechanisms of Global Climate Change at Millennial Time Scales. American Geophysical Union, Washington, DC, pp. 35-58.
  8. Broecker, W.S., 1994. Massive iceberg discharges as triggers for global climate change. Nature 372, 421-424.
  9. Broecker, W.S., Liu, T., 2001. Rock varnish: Recorder of desert wetness? GSA Today 11 (8), 4-10.
  10. Cremaschi, M., 1996. The desert varnish in the Messak Sattafet (Fezzan, Libryan Sahara), age, archaeological context and paleo-environmental implication. Geoarchaeology 11, 393-421.
  11. Colman, S.M., Pierce, K.L., Birkeland, P.W., 1987. Suggested terminology for Quaternary dating methods. Quaternary Research 28, 314-319.
  12. Dickerson, R.P., Forman, A., Liu, T., 2012. Co-development of alluvial fan surfaces and arid botanical communities, Stonewall Flat, Nevada, USA. Earth Surface Processes and Landforms, doi: 10.1002/esp.3336.
  13. Dorn, R.I., 1983. Cation-ratio dating: a new rock varnish age determination technique. Quaternary Research 20, 49-73.
  14. Dorn, R.I., 1984. Cause and implications of rock varnish microchemical laminations. Nature 310, 767-770.
  15. Dorn, R.I., 1988. A rock varnish interpretation of alluvial-fan development in Death Valley, California. National Geographic Research 4, 56-73.
  16. Dorn, R.I., 1990. Quaternary alkalinity fluctuations recorded in rock varnish microlaminations on western U.S.A. volcanics. Palaeogeography, Palaeoclimatology, Palaeoecology 76, 291-310.
  17. Dorn, R.I., Jull, A.J.T., Donahue, D.J., Linick, T.W., Toolin, L.J., 1989. Accelerator mass spectrometry radiocarbon dating of rock varnish. Geological Society of America Bulletin 101, 1363-1372.
  18. Fiedel, S. J., 1999. Older than we thought: Implications of corrected dates for Paleoindians. American Antiquity 64, 95-115.
  19. Fleisher, M., Liu, T., Broecker, W.S., Moore, W., 1999. A clue regarding the origin of rock varnish. Geophysical Research Letters 26, 103-106.
  20. Frankel, K. L., et al., 2007. Cosmogenic 10Be and 36Cl geochronology of offset alluvial fans along the northern Death Valley fault zone: Implications for transient strain in the eastern California shear zone, Journal of Geophysical Research 112, B06407, doi:10.1029/2006JB004350.
  21. Grootes, P.M., Stuiver, M., White, J.W.C., Johnsen, S., Jouzel, J., 1993. Comparison of oxygen isotope records from the GISP2 and GRIP Greenland ice core. Nature 366, 552-554.
  22. Lee, M.R., Bland, P.A., 2003. Dating climatic change in hot deserts using desert varnish on meteorite finds in Australia. Earth and Planetary Science Letters 206, 187-198.
  23. Liu, T., 1994. Visual microlaminations in rock varnish: a new paleoenvironmental and geomorphic tool in drylands. PhD thesis, Arizona State University, Tempe.
  24. Liu, T., 2003. Blind testing of rock varnish microstratigraphy as a chronometric indicator: results on late Quaternary lava flows in the Mojave Desert, California. Geomorphology 53, 209-234.
  25. Liu, T., Broecker, W.S., 2007. Holocene rock varnish microstratigraphy and its chronometric application in the drylands of western USA. Geomorphology 84, 1-21.
  26. Liu, T., Broecker, W.S., 2008. Rock varnish microlamination dating of late Quaternary geomorphic features in the drylands of western USA. Geomorphology 93, 501-523.
  27. Liu, T., Broecker, W.S., 2008. Rock varnish evidence for latest Pleistocene millennial-scale wet events in the drylands of western United States. Geology 36, 403-406.
  28. Liu, T., Broecker, W.S., 2013. Millennial-scale varnish microlamination dating of late Pleistocene geomorphic features in the drylands of western USA. Geomorphology 187, 38-60.
  29. Liu, T., Dorn, R.I., 1996. Understanding spatial variability in environmental changes in drylands with rock varnish microlaminations. Annals of the Association of American Geographers 86, 187-212.
  30. Liu, T., Broecker, W.S., 2000. How fast does rock varnish grow? Geology 28, 183-186.
  31. Liu, T., Broecker, W.S., Bell, J.W., Mandeville, C.W., 2000. Terminal Pleistocene wet event recorded in rock varnish from Las Vegas Valley, southern Nevada. Palaeogeography, Palaeoclimatology, Palaeoecology 161, 423-433.
  32. Machette, M.N., Slate, J.L., Phillips, F.M., 2008. Terrestrial Cosmogenic-nuclide Dating of Alluvial Fans in Death Valley, California. U.S. Geological Survey Professional Paper 1755, Reston, VA.
  33. Marrero, S., Phillips, F.M., Caffee, M.W., Smith, S.S., Kring, D.A., 2010. Re-dating the Barringer Meteorite Crater (AZ) impact using the cosmogenic chlorine-36 surface exposure method. 73rd Annual Meeting of the Meteoritical Society, held July 26– 30, 2010 in New York, New York. Meteoritics and Planetary Science, New York (Supplement, id.5150).
  34. Marston, R.A., 2003. Editorial note. Geomorphology 53, 197.
  35. Martinson, D.G., Pisias, N.G., Hays, J.D., Imbrie, J., Moore, T.C. Jr., Shackleton, N.J., 1987. Age dating and the orbital theory of the ice ages: development of a high-resolution 0 to 300,000-year chronostratigraphy. Quaternary Research 27, 1-29.
  36. Meese, D.A., Gow, A.J., Grootes, P., Mayewskiy, P.A., Ram, M., Stuiver, M., Taylor, K.C., Waddington, E.D., Zielinski, G.A., 1994. The accumulation record from the GISP2 core as an indicator of climate change throughout the Holocene. Science 266, 1680-1682.
  37. Moore, W.S., Liu, T., Broecker, W.S., Finkel, R.C., Wright, A., 2001. Factors influencing 7Be accumulation on rock varnish. Geophysical Research Letters 28, 4475-4478.
  38. Perry, R.S., Adams, J., 1978. Desert varnish: evidence of cyclic deposition of manganese. Nature 276, 489-491.
  39. Phillips, F.M., 2003. Cosmogenic 36Cl ages of Quaternary basalt flows in the Mojave desert, California, USA. Geomorphology 53, 199-208.
  40. Phillips, F.M., Zreda, M.G., Smith, S.S., Elmore, D., Kubik, P.W., Dorn, R.I., and Roddy, D.J., 1991. Dating the impact at Meteor Crater: Comparison of 36C1 buildup and varnish 14C with thermoluminesence. Geochimica et Cosmochimica Acta 55, 2695-2698.
  41. Potter, R.M., Rossman, G.R., 1977. Desert varnish: the importance of clay minerals. Science 196, 1446-1448.
  42. Potter, R.M., Rossman, G.R., 1979. The manganese- and iron-oxide mineralogy of desert varnish. Chemical Geology 25, 79-94.
  43. Reheis, M.C., Redwine, J., 2008. Lake Manix shorelines and Afton Canyon terraces: implications for incision of Afton Canyon. Geological Society of America Special Paper 439, 227–259. http://dx.doi.org/10.1130/2008.2439(10).
  44. Stirling, M., Ledgerwood, J., Liu, T., and Apted, M., 2010. Age of unstable bedrock landforms southwest of Yucca Mountain, Nevada, and implications for past ground motions. Bulletin of the Seismological Society of America 100, 74-86.
  45. Sutton, S.R., 1985. Thermoluminescence measurements on shock-metamorphosed sandstone and dolomite from Meteor Crater, Arizona. 2. Thermoluminescence age of Meteor crater. Journal of Geophysical Research 90, 3,690–3,700.
  46. Thiagarajan, N., Lee, C.T.A., 2004. Trace-element evidence for the origin of desert varnish by direct aqueous atmospheric deposition. Earth and Planetary Science Letters 224, 131-141.
  47. van der Woerd, J., Klinger, Y., Sieh, K., Tapponnier, P., Ryerson, F.J., and Meriaux, A., 2006. Long-term slip rate of the southern San Andreas fault from 10Be-26Al surface exposure dating of an offset alluvial fan. Journal of Geophysical Research 111, B04407, doi:10.1029/2004JB003559.
